Features
The product can be equipped with overload protection tools.
The shell made of high-quality alloy steel can better protect the gear box, and the chain case adopts the design of folding sides, which can improve the wear resistance of the shell.
The lifting chain, inside of which is an installed sealed bearing that reduces tension and maximizes strength.
The main body of the hoist can be connected by industrially replaceable pulley hooks.
The product is light in weight and easy to carry.
Parameter
| Model | Capacity (T) | Standard lifting height (M) | Running test load (T) | No.offalls of load chain | Load chain diameter (MM) | Net weight (KG) |
| CK 0.5T | 0.5 | 2.5 | 0.75 | 1 | 6 | 9 |
| CK 1T | 1 | 2.5 | 1.5 | 1 | 6 | 11.5 |
| CK 1.5T | 1.5 | 2.5 | 2.25 | 1 | 8 | 17.5 |
| CK 2T | 2 | 3 | 3 | 1 | 6 | 16 |
| CK 3T | 3 | 3 | 4.5 | 2 | 8 | 27 |
| CK 5T | 5 | 3 | 7.5 | 2 | 10 | 43 |
| CK 10T | 10 | 3 | 15 | 4 | 10 | 75 |
| CK 20T | 20 | 3 | 30 | 8 | 10 | 185 |
