The flat webbing sling can provide a wide bearing surface, which is especially suitable for hoisting objects with soft surfaces. This product can also be equipped with a wider protecting sheath for use if necessary. Because the sling is relatively soft, the damage to the surface of the lifted object is extremely slight. We can use polyester, polypropylene, nylon and other raw materials according to customers' needs.
Applications:
this product is mainly used in port, chemical industry, iron and steel industry, machinery, petroleum industry, electric power industry, railway, mine, metallurgy industry, shipbuilding, automobile, aerospace, army and many other fields.
Characteristic
Light weight. The weight of this product is only 20% of that of the metal lifting appliance with the same lifting capacity.
This product conforms to European Standard EN1492-1:2000 and Chinese Industry Standard JB/T8521-2007
Parameter
| Model | Capacity (kg) | ApproxThickness (mm) | ApproxWidth (mm) | Min Length (m) | Max Length (m) | Eye Length (mm) |
| EB-01 | 1000 | 7.5 | 30 | 1.1 | 100 | 350 |
| EB-02 | 2000 | 7.5 | 60 | 1.2 | 100 | 400 |
| EB-03 | 3000 | 7.5 | 90 | 1.3 | 100 | 450 |
| EB-04 | 4000 | 7.5 | 120 | 1.4 | 100 | 500 |
| EB-05 | 5000 | 7.5 | 150 | 2.0 | 100 | 550 |
| EB-06 | 6000 | 7.5 | 180 | 2.0 | 100 | 600 |
| EB-08 | 8000 | 7.5 | 240 | 2.0 | 100 | 700 |
| EB-10 | 10000 | 7.5 | 300 | 3.0 | 100 | 800 |
| EB-12 | 12000 | 7.5 | 350 | 3.0 | 100 | 900 |
