Features
Double-pawl brake system and more elastic pawl spring ensure the braking stability of this product.
The double guide wheel structure makes the lifting wheel more stable, and it will effectively prevent the chain from jamming.
This hand chain driven is designed with folding sides. Even being pulled obliquely, the hand chain drive can maintain smooth and stable operation.
The product is light in weight and easy to carry.
Parameter
| Model | Capacity (T) | Standard lifting height (M) | Running test load (T) | No.offalls of load chain | Load chain diameter (MM) | Net weight (KG) |
| HS-Z 0.25T | 0.25 | 2 | 0.375 | 1 | 4 | 3.5 |
| HS-Z 0.5T | 0.5 | 2.5 | 0.75 | 1 | 6 | 7 |
| HS-Z 1T | 1 | 2.5 | 1.5 | 1 | 6 | 10 |
| HS-Z 1.5T | 1.5 | 2.5 | 2.25 | 1 | 8 | 15 |
| HS-Z 2T | 2 | 2.5 | 3 | 2 | 6 | 14 |
| HS-Z 3T | 3 | 3 | 4.5 | 2 | 8 | 24 |
| HS-Z 5T | 5 | 3 | 7.5 | 2 | 10 | 36 |
| HS-Z 10T | 10 | 3 | 15 | 4 | 10 | 75 |
| HS-Z 15T | 15 | 3 | 22.5 | 6 | 10 | 117 |
| HS-Z 20T | 20 | 3 | 30 | 8 | 10 | 164 |
| HS-Z 30T | 30 | 3 | 45 | 12 | 10 | 400 |
